Mã lỗi máy photocopy Xerox DocuCentre-V 2060/3060/3065

Mã lỗi máy photocopy Xerox DocuCentre-V 2060/3060/3065

Một số mã lỗi thường gặp ở máy photocopy Xerox DocuCentre-V 2060/3060/3065

Code: 010-397
Display: 010-397 Restart Printer Contact Support If Message Returns
Description: Fusing Failure Fusing temperature anomaly detected

Code: 016-315
Display: 016-315 Restart Printer Contact Support If Message Returns
Description: DRAM check failure DRAM check error occurred

Code: 016-317
Display: 016-317 Restart Printer Contact Support If Message Returns
Description: ROM content invalid Invalid ROM content detected.

Code: 016-501
Display: 016-501 Write Flash Error Contact Support If Message Returns
Description: Write Flash Error Can not update application code in FLASH

Code: 016-502
Display: 016-502 Write Flash Error Contact Support If Message Returns
Description: Write Flash Error Can not update parameters in FLASH

Code: 016-718
Display: 016-718 Memory Full Job Failure Press Ok
Description: Memory Over flow The current job exceeds memory capacity.

Code: 016-719
Display: 016-719 Decode Error Job Failure Press Stop to Cancel
Description: Decode error Decode error is detected.

Code: 016-720
Display: 016-720 PDL Request Data Violation Press Ok
Description: PDL Error The print data cannot be processed by PDL

Code: 016-744
Display: 016-744 Format Error Invalid Data Press Ok
Description: Download Format Error Invalid code to be downloaded.

Code: 016-745
Display: Format Error Invalid Data Press Ok
Description: Download Format Error Invalid code to be downloaded.

Code: 016-749
Display: 016-749 PJL Request Data Violation Press Ok
Description: PJL Request Error Print data cannot be processed by PJL

Code: 024-340
Display: Restart Printer Contact Support If Message Returns
Description: MCU Firmware Error

Code: 024-360
Display: 024-360 Restart Printer Contact Support If Message Returns
Description: MCU Firmware DownLoad Error

Code: 024-371
Display: 024-371 Restart Printer Contact Support If Message Returns
Description: MCU-ESS Communication Fail Communication fail between MCU and ESS
Description: Paper Size Mismatch The size of paper in the Tray does not match the specified print size XXXXXX: Paper Size YYYYYY: Paper TypE

Code: 024-963

Description: No Paper/Jam Tray has run out of paper, or Regi sensor is not turned ON within the specified time.

Display: 024-963 No Paper Load Paper then Press Ok XXXXX (or YYYYY)
Description: No Paper/Jam Tray has run out of paper, or Regi sensor is not turned ON within the specified time.

Code: 041-340
Display: 041-340 Restart Printer Contact Support If Message Returns
Description: NVM (read/write error detected.

Code: 061-370
Display: 061-370 Restart Printer Contact Support If Message Returns
Description: LPH failure detected.

Code: 075-100
Display: 075-100 Paper Jam Jam at Feed Open Rear Cover and Remove Paper
Description: No Paper/Jam Tray is out of paper, or Regi sensor is not turned ON within the specified time.

Code: 075-921
Display: 075-921 Insert Output to Tray Press Ok to Continue Printing
Description: Insert Output to Tray The sheet on which to print an oddnumbered page has not been loaded in the Tray for manual duplex printing.

Code: 077-100
Display: 077-100 Paper Jam Jam at Feed Open Rear Cover and Remove Pape
Description: No Paper/Jam Tray is out of paper, or Regi sensor is not turned ON within the specified time.

Code: 077-104
Display: 077-104 Paper Jam Jam at Exit Open Rear Cover and Remove Paper
Description: Regi Jam The paper does not pass through the Regi Sensor on time.

Code: 077-106
Display: 077-106 Paper Jam Jam at Exit Open Rear Cover and Remove Paper
Description: No Paper/Jam Tray is out of paper, or Regi sensor is not turned ON within the specified time.

Code: 077-108
Display: 077-108 Paper Jam Jam at Exit Open Rear Cover and Remove Paper
Description: Exit Jam The paper does not pass through the Exit Sensor on time.

Code: 077-109
Display: 077-109 Paper Jam Jam at Exit Open Rear Cover and Remove Paper
Description: Exit Jam The paper does not pass through the Exit Sensor on time.

Code: 077-304
Display: 077-304 Close Rear Cover
Description: Rear Cover Open

Code: 077-900
Display: 077-900 Paper Jam at Exit Open Rear Cover and Remove Paper
Description: Paper Remains at Exit Paper remains in Exit Sensor.

Code: 077-901
Display: Paper Jam at Exit Open Rear Cover and Remove Paper
Description: Paper Remain at Regi Sensor.

Code: 091-402
Display: 091-402 Restart Printer Contact Support If Message Returns
Description: Xero Near Life

Code: 092-651
Display: 092-651 Restart Printer Contact Support If Message Returns
Description: CTD (ADC) sensor error

Code: 092-661
Display: 092-661 Restart Printer Contact Support If Message Returns
Description: Environment Sensor Error The Environment Sensor detected a temperature anomaly

Code: 093-426
Display: 093-426 Toner Cartridge is Close to Life
Description: Toner Cartridge Life Warning The Toner Cartridge is approaching the replacement time

Code: 093-926
Display: 093-926 CRUM ID Reseat Black Cartridge
Description: K CRUM ID Error An unsupported Toner Cartridge is detected.

Code: 093-933
Display: 093-933 Replace the toner cartridge or check the cartridge is correctly set
Description: Toner Cartridge Life Over (K) The Toner Cartridge has reached the replacement time

Code: 093-974
Display: 093-974 Insert Print Cart Insert Toner Cartridge
Description: Toner Cartridge Detached The Toner Cartridge is not installed

Code: 116-314
Display: 116-314 Restart Printer Contact Support If Message Returns
Description: ESS Network MAC Checksum Error Checksum error in MAC address.

Code: 116-323
Display: 116-323 Restart Printer Contact Support If Message Returns
Description: Checksum error (Fax) Checksum error for Fax parameter is detected.

Code: 116-325
Display: 116-325 Restart Printer Contact Support If Message Returns
Description: Checksum error (Other)

Code: 116-326
Display: 116-326 Restart Printer Contact Support If Message Returns
Description: Checksum error for Scannr parameter is detected.

Code: 116-335
Display: 116-335 Restart Printer Contact Support If Message Return
Description: Checksum error (Network) Checksum error for Network parameter is detected.

Code: 116-355
Display: 116-355 Restart Printer Contact Support If Message Return
Description: ESS Network Fatal Error. Error during the onboard network check.

Code: 117-331 … 117 366
Display: 117-331 Restart Printer Contact Support If Message Return
Description: ESS-related error

Code: 124-333
Display: 124-333 Restart Printer Contact Support If Message Return
Description: ASIC Failure ASIC failure detected

Code: 191-310
Display: 191-310 Restart Printer Contact Support If Message Return
Description: XERO Life Over The Printer has reached the replacement time
